The Porcelain Lighting Housed Arrester protects electrical systems from overvoltage transients caused by lightning strikes or switching operations. It employs zinc oxide varistor technology within a robust porcelain casing, ensuring reliable protection for critical infrastructure. These arresters comply with international standards such as IEC (International Electrotechnical Commission) 60099-4 and ANSI (American National Standards Institute)/IEEE (Institute of Electrical and Electronics Engineers) C62.11, undergoing rigorous testing to verify performance under various electrical stresses.
Applications span substations for safeguarding transformers, reactors, and circuit breakers, as well as power generation, transmission, and distribution networks. They suit industrial installations, capacitor banks, and environments with high mechanical loads or pollution levels, providing consistent overvoltage mitigation across diverse electrical systems.
Key advantages include high surge handling capability and thermal stability, contributing to minimal maintenance costs and long-term reliability. Each unit undergoes quality tests such as energy withstand and impulse current tests, ensuring consistent operation and adherence to industry standards. The high-strength porcelain housing offers superior insulation and arc resistance, withstanding harsh weather conditions and mechanical stress while preventing moisture ingress through sealed design.
Technical specifications include rated voltages from 3 kV to 500 kV with nominal discharge currents of 5 kA or 10 kA. The arresters handle high current impulse withstands up to 100 kA for 4/10 μs waves, operating across temperatures from -40°C to +70°C and altitudes up to 2000 meters.
Porcelain Lighting Housed Arrester Wholesaler with 21 Years of Expertise
Introduction
RaxPower is a leading manufacturer and supplier specializing in high-quality electrical solutions, including porcelain lighting housed arresters. With 21 years of experience, we provide reliable, innovative, and customizable products tailored to meet international standards. Our solutions are endorsed by major clients such as State Grid Corporation of China and China Southern Power Grid, ensuring trust and performance in every application.
Product Features
Our porcelain lighting housed arrester is designed to protect your electrical equipment and infrastructure from the destructive power of lightning strikes. It features a high-strength porcelain body that stands up to extreme temperatures, mechanical stress, and environmental exposure over long periods. Designed for seamless integration with transformers, breakers, and other equipment, this arrester offers reliable surge protection while maintaining a compact and maintenance-free structure, ideal for utilities and industrial applications.
Quality Assurance
We employ strict quality control systems and advanced testing procedures to ensure the reliability and durability of our porcelain lighting housed arresters. Our team conducts rigorous tests, including impact and thermal shock tests, using high-quality raw materials and advanced manufacturing technologies. All products are reviewed multiple times before packing to guarantee 100% quality and compliance with industry standards.
Conclusion
As a trusted manufacturer with a commitment to excellence, we guarantee the performance and longevity of our porcelain surge arresters. Contact us today to learn more about our porcelain lighting housed arresters and how they can benefit your company.
| Nominal Discharge Current (kA) | Model Type | Rated Voltage (kV rms) | MCOV (kV rms) | Power Frequency Discharge Voltage (kV) | 1.2/50 μs Impulse Discharge Voltage (kV crest) | 8/20 μs Lightning Impulse Residual Voltage (kV crest) | 2 ms Rectangular Current Impulse Withstand (A) | 4/10 μs High Current Impulse Withstand (kA crest) | Line Discharge Class |
|---|---|---|---|---|---|---|---|---|---|
| 5 | Y5C-3 | 3 | 2.55 | 5 | 7.8 | 9 | 100 | 65 | |
| 5 | Y5C-6 | 6 | 5.1 | 10 | 15.5 | 18 | 100 | 65 | |
| 5 | Y5C-9 | 9 | 7.65 | 16.5 | 24.5 | 27 | 100 | 65 | |
| 5 | Y5C-12 | 12 | 10.2 | 21 | 32.6 | 36 | 100 | 65 | |
| 5 | Y5C-15 | 15 | 12.7 | 25 | 38.8 | 45 | 100 | 65 | |
| 5 | Y5C-18 | 18 | 15.3 | 31 | 48.1 | 54 | 100 | 65 | |
| 5 | Y5C-21 | 21 | 17.0 | 34 | 52.7 | 63 | 100 | 65 | |
| 5 | Y5C-24 | 24 | 19.2 | 39 | 60.5 | 75 | 100 | 65 | |
| 5 | Y5C-27 | 27 | 21.9 | 45 | 69.8 | 81 | 100 | 65 | |
| 5 | Y5C-30 | 30 | 24.4 | 50 | 77.5 | 90 | 100 | 65 | |
| 5 | Y5C-33 | 33 | 26.8 | 55 | 85.3 | 99 | 100 | 65 | |
| 5 | Y5C-36 | 36 | 29.0 | 60 | 93.0 | 108 | 100 | 65 | |
| 5 | Y5C-42 | 42 | 34.1 | 70 | 108.5 | 126 | 100 | 65 | |
| 10 | Y10C-3 | 3 | 2.55 | 9.5 | 7.7 | 9 | 100 | 100 | 1 |
| 10 | Y10C-6 | 6 | 5.1 | 19.5 | 15.4 | 18 | 100 | 100 | 1 |
| 10 | Y10C-9 | 9 | 7.65 | 28.5 | 23.1 | 27 | 100 | 100 | 1 |
| 10 | Y10C-12 | 12 | 10.2 | 38.0 | 30.8 | 36 | 100 | 100 | 1 |
| 10 | Y10C-15 | 15 | 12.7 | 47.5 | 38.5 | 45 | 100 | 100 | 1 |
| 10 | Y10C-18 | 18 | 15.3 | 57.0 | 46.2 | 54 | 100 | 100 | 1 |
| 10 | Y10C-21 | 21 | 17.0 | 66.5 | 53.9 | 63 | 100 | 100 | 1 |
| 10 | Y10C-24 | 24 | 19.2 | 76.0 | 61.6 | 72 | 100 | 100 | 1 |
| 10 | Y10C-27 | 27 | 21.9 | 85.5 | 69.3 | 81 | 100 | 100 | 1 |
| 10 | Y10C-30 | 30 | 24.4 | 95.0 | 76.5 | 90 | 100 | 100 | 1 |
| 10 | Y10C-33 | 33 | 26.8 | 104.5 | 84.7 | 99 | 100 | 100 | 1 |
| 10 | Y10C-36 | 36 | 29.0 | 114.0 | 92.4 | 108 | 100 | 100 | 1 |
| 10 | Y10C-42 | 42 | 34.1 | 132.3 | 100.1 | 126 | 100 | 100 | 1 |
Frequently Asked Questions (FAQS)
What is a porcelain lighting housed arrester and how does it function?
A porcelain lighting housed arrester is a surge protection device that safeguards electrical equipment from over-voltage transients caused by lightning strikes or switching operations. It features a durable porcelain housing encasing metal-oxide varistors (MOVs). When a surge occurs, the MOVs rapidly reduce their resistance, creating a low-impedance path that safely diverts surge energy to ground, protecting connected equipment.
What are the key advantages of porcelain housed arresters?
Porcelain housed arresters offer high mechanical strength and durability, excellent performance in high-contamination environments, long service life, and proven reliability under extreme weather conditions. They are maintenance-free and provide consistent overvoltage protection.
In what applications are porcelain lighting arresters typically used?
They are commonly used in high-voltage substations, transmission lines, industrial power systems, and areas with high pollution levels. They protect transformers, circuit breakers, and other critical infrastructure from lightning and switching surges.
How do your porcelain arresters perform in harsh environmental conditions?
Our porcelain-housed arresters withstand extreme temperatures from -40°C to +70°C, high humidity, UV exposure, and chemical pollutants. The robust porcelain housing provides excellent mechanical strength, insulation, and extended creepage distances, making them ideal for polluted, coastal, or industrial environments without requiring maintenance.
What maintenance is required for porcelain lighting arresters?
Maintenance includes regular visual inspections for physical damage, contamination, or signs of electrical discharge. Cleaning of the porcelain surface may be needed in polluted areas, and periodic testing of electrical performance, such as leakage current measurements, is recommended.
How do porcelain arresters compare to polymeric surge arresters?
Porcelain arresters are known for their mechanical strength and durability, making them suitable for harsh environments, but they are heavier and more prone to shattering. Polymeric arresters are lighter, more resistant to environmental degradation, and offer better shatter resistance.
What factors should be considered when selecting a porcelain lighting arrester?
Key factors include the maximum continuous operating voltage (MCOV), rated voltage, energy absorption capacity, nominal discharge current rating, environmental conditions (e.g., pollution levels, temperature), and specific application requirements such as for substations or transmission lines.
How do you ensure standards compliance and long-term reliability for critical infrastructure?
Our arresters are manufactured under strict quality control with rigorous raw material selection and multi-stage testing. They comply with international standards such as IEC 60099-4 and ANSI/IEEE C62.11, and have passed third-party tests including SGS evaluations. Each unit undergoes energy withstand tests, classification, and accelerated life testing to ensure consistent performance and durability for grid applications.
What is your manufacturing capacity and lead time for large volume orders?
We have substantial production capacity with 17,000 square meters of production space and 5,000 square meters of warehousing, supported by automated processes. We can supply high volumes annually and typically deliver within 25 days from contract signing, ensuring on-time delivery for bulk orders from EPC contractors or distributors.
Do you offer custom manufacturing or OEM services?
Yes, we provide comprehensive ODM and OEM services, including custom forging, casting, and manufacturing according to customer specifications. Our one-stop approach delivers tailored solutions for unique design needs or large-scale projects, ensuring products meet exact technical and application requirements without compromising quality.
