The Pole Transformer Bracket securely mounts distribution transformers on utility poles, supporting single-phase and three-phase applications. Constructed from high-grade steel or ductile iron with hot-dipped galvanized coating per ASTM A153 standards, the bracket resists corrosion, moisture, and environmental stressors. Heavy-duty models support loads up to 15,000 pounds when properly installed, with individual positions handling 2,000 to 5,000 pounds depending on design.
The bracket accommodates pole diameters from 6 to 12 inches and transformers ranging from 3kVA to 333kVA, including single-phase models up to 167kVA. Common configurations support one to three transformers, with mounting hole spacings of 12 or 24 inches for National Electrical Manufacturers Association (NEMA) A or American National Standards Institute (ANSI) B lug types. Adjustable mounting points enable flexible configurations, while a jump-proof lip prevents accidental dislodging.
Installation uses provided hardware including machine bolts, nuts, and lockwashers to secure the bracket firmly. Some models allow ground-level assembly with transformers before hoisting via welded lifting eyes. The bracket meets industry standards including International Organization for Standardization (ISO) 9001, ASTM A153, and Rural Utilities Service (RUS) approval, ensuring certified compliance and reliable performance under operational stresses and diverse weather conditions.
Trusted Pole Transformer Bracket Wholesaler
RaxPower, as China’s leading manufacturer of pole line hardware, specializes in the R&D, production, and sales of pole transformer brackets engineered to the highest industry specifications. We are obsessive about quality and proudly ISO 9001:2015 certified. With over 21 years of industry experience since our establishment in 2003, we have built an enviable reputation that we protect by offering an industry-best 2 Year Guarantee on all our brackets. Our commitment to reliability is backed by strategic stock investments, ensuring the shortest possible lead times for every order. Each bracket is hot-dip galvanized to meet ASTM A153 standards, providing superior corrosion resistance and strength for secure transformer mounting. Our dedicated service team responds swiftly to deliver cost-efficient and dependable solutions every time.
For your Pole Transformer Bracket needs, refer to our comprehensive catalog for a full selection of sizes and types. Provide the part number to receive a quick quote, leave a message, send us an email, or call our expert team directly to get answers to your questions and place your order with confidence.
| Parameter | Specification |
|---|---|
| Material | High-grade steel or ductile iron |
| Finish | Hot-dipped galvanized per ASTM A153 |
| Pole Diameter Range | 6 inches to 12 inches |
| Transformer kVA Range | 3 kVA to 333 kVA |
| Number of Positions | 1, 2, or 3 |
| Load Capacity per Position | 2,000 pounds to 5,000 pounds |
| Total Load Capacity | Up to 15,000 pounds |
| Mounting Hole Spacing | 12 inches or 24 inches |
| Lug Spacing Type | NEMA A or ANSI B |
| Bolt Sizes (Transformer) | 5/8-inch or 3/4-inch machine bolts |
| Recommended Pole Fasteners | 3/4-inch machine bolts and 1/2-inch lag screws |
| Certifications | ISO 9001, ASTM A153, RUS approval |
| Standards | ASTM A153 |
Frequently Asked Questions (FAQS)
What is a pole transformer bracket and what materials are used?
A pole transformer bracket is an essential component used for securely mounting distribution transformers to utility poles, ensuring stable operation under various environmental conditions. These brackets are made from weather-resistant materials such as hot-dipped galvanized steel or ductile iron, providing corrosion resistance and enhanced durability while supporting transformers ranging from single-phase to three-phase models.
What are the standard sizes and weight capacities?
Standard pole transformer brackets accommodate transformers ranging from 3kVA to 333kVA and are designed for utility poles with diameters from 6 inches to 12 inches. Weight capacity varies by design, with heavy-duty models supporting up to 15,000 lbs when properly installed. Custom sizes are available to meet specific installation requirements.
How do I install a pole transformer bracket safely?
Select an appropriate location on the utility pole, align the bracket with the transformer, and secure it using the provided hardware such as machine bolts and nuts. Wear appropriate personal protective equipment (PPE), follow local electrical codes and regulations, and ensure the area is free from hazards. Consulting with a licensed electrician is advisable for complex installations.
Can I use a single bracket for multiple transformers?
Some pole transformer brackets are designed for multiple units, but it is crucial to check compatibility with the number and type of transformers being mounted to ensure safety and stability.
What certifications and quality control processes do you maintain?
We hold ISO 9001, ISO 14001, and ISO 18001 certifications and implement a comprehensive quality control plan. All products undergo rigorous testing, including load tests and gauge tests, to ensure they meet industry standards and provide dependable performance in critical applications.
What is your production capacity and do you offer custom services?
Our production capacity is 15,000 sets per month with short lead times to meet tight project schedules. We provide OEM services and custom sizes tailored to your specific requirements, ensuring perfect fit and on-time delivery for bulk orders and specialized applications.
What after-sales support do you provide?
We offer dependable after-sale service with quick response to inquiries and complete documentation ready for tender submissions, including all necessary certifications and technical specifications.
