Square Curved Washers are fastening components with a curved profile that conforms to rounded surfaces such as utility poles. The curved surface matches pole contours while distributing load evenly, preventing deformation of wood or composite materials under heavy loads. The square geometry provides a larger surface area than round washers, reducing material crushing risk, and offers anti-rotation properties that maintain bolt stability in high-vibration environments.
These washers are manufactured from carbon steel or stainless steel to suit different environmental and mechanical requirements. Hot dip galvanized coatings per American Society for Testing and Materials (ASTM) A153 provide corrosion protection, while thermal diffusion galvanized options (ASTM A1059) offer enhanced resistance and extended service life. Common sizes include 2-1/4 inches by 2-1/4 inches with 3/16-inch thickness or 4 inches by 4 inches with 1/4-inch thickness, accommodating bolt diameters from 1/2 inch to 1 inch.
Applications include utility pole line hardware, protecting wood fibers from crushing, as well as construction, structural engineering, marine environments, bridges, and renewable energy installations. Products meet Rural Utilities Service (RUS) approval for specific catalog numbers, ASTM standards, Canadian Standards Association (CSA) C83-96, and National Electrical Manufacturers Association (NEMA) PH-10 requirements. Custom manufacturing accommodates non-standard sizes, materials, and finishes for project-specific needs.
Trust RaxPower for Reliable Square Curved Washer Wholesaler
Enhance the performance and longevity of your fastening systems with Square Curved Washer from RaxPower, China’s premier manufacturer of pole line hardware. Established in 2003 and based in Hebei Province, RaxPower brings over 21 years of expertise in R&D, production, and sales, with a focus on quality and precision at the core of manufacturing. Our square curved washers are crafted using advanced hot forging technology, resulting in greater strength and accurate sizing, and are made from high-quality steel with hot-dip galvanizing for superior corrosion protection, ensuring a smooth, stable surface that distributes pressure evenly and resists rotation.
These washers feature a larger surface area for maximum load distribution, reducing the risk of loosening and material deformation in applications such as:
- mechanical equipment
- building bridges
- power transmission systems
In real-world case studies, installations have shown over 40% improvement in bolt stability under dynamic loads. RaxPower’s strict quality control, including automatic machining and multi-stage testing, guarantees durability and reliability. Buy bulk square curved washers at competitive prices directly from our website for your custom or standard needs.
| Size (Inches) | Hole Diameter (Inches) | Bolt Diameter (Inches) | Weight/100 (lbs) | Material | Coating |
|---|---|---|---|---|---|
| 2-1/4 x 2-1/4 x 3/16 | 11/16 | 5/8 | 26.0 | Steel | Hot dip galvanized (ASTM A153) |
| 3 x 3 x 1/4 | 11/16 | 5/8 | 65.0 | Steel | Hot dip galvanized (ASTM A153) |
| 3 x 3 x 1/4 | 13/16 | 3/4 | 56.5 | Steel | Hot dip galvanized (ASTM A153) |
| 3 x 3 x 1/4 | 13/16 | 3/4 | 56.5 | Steel | Thermal diffusion galvanized (ASTM A1059) |
| 4 x 4 x 1/4 | 15/16 | 7/8 | 117.0 | Steel | Hot dip galvanized (ASTM A153) |
| 4 x 4 x 1/4 | 13/16 | 3/4 | 117.0 | Steel | Hot dip galvanized (ASTM A153) |
Frequently Asked Questions (FAQS)
What are square curved washers and what are they used for?
Square curved washers are fastening components designed to match curved surfaces, primarily utility poles. They avoid sharp corners, distribute loads evenly across a larger surface area, and prevent deformation of wood or composite poles. Applications include utility pole line hardware, mechanical equipment, electronic equipment, communication equipment, and building bridges.
What materials and coatings are available?
Square curved washers are typically made from steel with hot-dipped galvanizing for corrosion protection. Enhanced options include thermal diffusion galvanizing (TDG), which provides superior corrosion resistance and longer service life, complying with standards such as ASTM A1059.
What sizes are available for square curved washers?
Sizes include 2-1/4 x 2-1/4 x 3/16 , 3 x 3 x 1/4 , and 4 x 4 x 1/4 , with hole diameters ranging from 11/16 to 15/16 to accommodate bolt diameters from 1/2 to 1 . Weights per 100 pieces vary from 26.0 lbs to 117.0 lbs depending on size and thickness.
Can I order custom-sized square curved washers?
Yes, square curved washers can be custom manufactured to your exact specifications, including size, hole diameter, thickness, and coating options to meet specific application requirements, load needs, or environmental conditions.
