The Auxiliary Eye is a clamp that adds an eye to an existing anchor rod for attaching additional guy wires in utility and communication infrastructure. The design features a wide radius eye to prevent kinking or injury to the guy strand, and in some configurations eliminates the need for a separate thimble. It also functions as a pulling eye for tensioning guys during installation.
The clamp bolts onto the anchor rod, typically below the rod head, enabling additional guying points on already installed anchors without modifying the primary anchor. This supports stability in various structural setups where extra guy lines are needed.
The Auxiliary Eye is constructed from cast ductile iron body and spacers, hot dip galvanized per American Society for Testing and Materials (ASTM) A-153 for corrosion resistance. It accommodates anchor rod diameters from 5/8 inch to 1-1/4 inch and features a minimum ultimate tensile strength of 18,000 pounds. The thimble hole measures 5/8 inch by 1 inch to 1.5 inches in diameter depending on model, with 1/2 inch diameter U-bolts.
Catalog numbers include AE155 and BB155A. Units weigh approximately 3 pounds with dimensions of 5.75 inches length, 4.125 inches width, and 2.875 inches height.
Auxiliary Eye Supplier for Reliable Guy Attachment
RaxPower, established in 2003 in Hebei Province, China, is a leading manufacturer of pole line hardware with 21 years of experience. Our extensive production facilities spanning 17,000 square meters and a dedicated team of over 170 employees, including 30 professional technicians and 10 engineers, enable us to deliver efficient and reliable industrial solutions.
The Auxiliary Eye clamp permits an efficient method of adding an eye to an existing anchor rod for attaching an additional guy. It features a generous 1.5 inch diameter thimble for secure and reliable attachment, is easily bolted onto the rod for a well-secured fit, and is constructed from Hot Dip Galvanized materials for superior corrosion resistance and durability.
Our advanced manufacturing processes, such as hot forging for greater strength and accurate sizing, combined with strict quality control including load testing and galvanizing thickness checks ensuring a mean coating over 85 microns, guarantee that every Auxiliary Eye meets high standards of performance and safety in power line applications.
| Catalog Number | Thimble Size | Anchor Rod Diameter Range (in) | Strand Size (in) | Ultimate Tensile Strength (lbs) | Weight (lbs) | U-bolt Diameter (in) | Material | Coating | Dimensions (L x W x H in) |
|---|---|---|---|---|---|---|---|---|---|
| AE155-A | 1.5″ diameter | 3/4″ – 1″ | 1/2″ | 18,000 | 3.0 | 1/2″ | Cast ductile iron | Hot dip galvanized per ASTM A-153 | Not specified |
| AE155 | 1.5″ diameter | 5/8″ – 3/4″ | 1/2″ | 18,000 | 2.5 | 1/2″ | Cast ductile iron | Hot dip galvanized per ASTM A-153 | Not specified |
| AE155-B | 1.125″ diameter | 1″ – 1-1/4″ | 9/16″ | 18,000 | 3.0 | 1/2″ | Cast ductile iron | Hot dip galvanized per ASTM A-153 | Not specified |
| BB155A | 5/8″ x 1″ (rectangular) | 5/8″ – 1″ | Not specified | 18,000 | 3.01 | 1/2″ | Ductile iron, ASTM A-536 | Galvanized per ASTM A-153 | 5.75 x 4.125 x 2.875 |
Frequently Asked Questions (FAQS)
What is the primary function of the Auxiliary Eye?
The Auxiliary Eye permits an efficient method of adding an eye to an existing anchor rod for attaching an additional guy wire. It can also be used as a pulling eye for tensioning guys.
How do your auxiliary eyes comply with industry standards for safety and reliability?
Our auxiliary eyes are designed and manufactured in compliance with applicable electric utility and communications industry standards. They are constructed from cast ductile iron with hot-dip galvanized finish per ISO 1461, ensuring corrosion resistance, durability, and consistent quality for reliable performance in grid maintenance, expansion, renewable energy connections, and railway catenary systems.
What load capacity do your auxiliary eyes offer?
The auxiliary eyes have a minimum ultimate tensile strength of 18,000 lbs, making them suitable for demanding applications where high durability and strength are essential for long-term reliability.
What size ranges are available to fit different anchor rod diameters?
Our auxiliary eyes accommodate rod diameters from 5/8″ to 1″, with specific models covering ranges like 3/4″ to 1″ and 5/8″ to 3/4″. This variety allows distributors and electrical contractors to stock products that meet diverse installation needs.
How is the Auxiliary Eye installed on an anchor rod?
Bolt the auxiliary eye onto the rod so it is well secured using U-bolts. The eye features a generous 1.5 inch diameter thimble, and the U-bolts are 1/2″ in diameter.
Get A Quick Quotation Today
