The guy attachment is a hardware component that fastens guy wires to utility poles, including both steel and wood types. It features a well-rounded strand groove that protects the guy strand from damage during installation and use, while offering flexibility for terminating various guy wires or fiberglass strain insulators. The design helps prevent guy wire creep in applications involving wrapped strands or angled poles, ensuring stable tension distribution.
Guy attachments are constructed from high-quality materials such as American Iron and Steel Institute (AISI) 1018 grade steel, ductile iron, or aluminum variants. Manufacturing processes involve stamping or forming to create a robust structure that withstands mechanical stresses. The finish is typically hot dip galvanized, conforming to ASTM Specification A153, which provides resistance to moisture, corrosion, and environmental conditions.
Specifications include an ultimate strength of up to 19,000 pounds at a 45-degree pull angle or a tensile strength rating of 10,000 pounds. Common dimensions feature a stock size of 1/4 inch by 2 inches, a mounting hole diameter of 11/16 inch, and an offset angle of 45 degrees. The attachment accommodates maximum cable diameters up to 1/2 inch and is suitable for use on round or flat surfaces.
Leading Guy Attachment Wholesaler
Because RaxPower, established in 2003 and located in Hebei Province, is one of the leading guy attachment factories in China, our Guy Attachment is engineered for fastening guy wires to telephone poles and utility structures, providing an economical and reliable solution with stable tension distribution.
Made from hot-dip galvanized steel using advanced manufacturing processes like hot forging, it ensures exceptional corrosion resistance, high mechanical strength, and a smooth finish for long service life.
We constantly think and practice, adhering to a growth-oriented philosophy focused on delivering high-quality solutions at competitive prices to clients throughout the planet. Our Guy Attachments have passed a series of standard type tests in our internal laboratory, including tensile strength and corrosion resistance tests, validated through strict quality control and SGS certifications to guarantee durability and performance.
We offer comprehensive OEM and ODM services, and you can get free samples to test your project application.
Other Products You May Like
Frequently Asked Questions (FAQS)
What is the primary purpose of a guy attachment?
The guy attachment provides an economical and efficient means of fastening guy wires to poles, ensuring stable tension distribution and preventing slippage.
What makes your guy attachments suitable for harsh environmental conditions?
Constructed from press-formed or stamped steel and hot-dip galvanized to meet ASTM Specification A153, our guy attachments provide high strength, corrosion resistance, and long service life. The well-rounded wire groove protects the strand from crushing and abrasion, ensuring durability even in demanding environments like coastal or high-vibration areas.
How do your guy attachments help in reducing overall project costs?
Our guy attachments offer cost savings through easy installation with a single bolt and reliable performance that minimizes maintenance needs. Their durability and consistent quality help avoid downtime and replacement expenses, making them a cost-effective choice for various projects.
What is the strength rating of the guy attachment?
The guy attachment has an ultimate strength of up to 19,000 lbs at a 45° pull, with some models offering a tensile strength of 10,000 lbs.
What are the key dimensions of the guy attachment?
Standard dimensions include a hole diameter of 11/16 , a stock size of approximately 1/4 x 2 , and an overall length of 2 inches.
How is the guy attachment installed on a pole?
Installation involves mounting the attachment using a single bolt, typically 5/8 in diameter, and it can be used with universal pole bands for secure fastening.
Is the guy attachment compatible with different types of poles?
Yes, it is designed for use with both steel and wood poles and can be applied on round or flat surfaces.
Can you create custom guy attachments for specific applications?
Yes, we offer OEM and ODM services to customize guy attachments according to your project requirements, ensuring a perfect fit and functionality.
