The Dome Closure protects fiber optic splices in outdoor and underground environments. Its dome-shaped structure houses and safeguards spliced fibers while maintaining reliable performance in demanding conditions. The closure features a patented segmented end plate allowing independent access to each cable port without disrupting adjacent cables, and a hinged collar system enables quick reentry without special tools. An integrated air valve facilitates flash testing of the closure seal.
The flexible grommet sealing system accommodates a wide range of flat or round cable profiles, supporting high-density splice configurations. Constructed from flame-retardant and UV-stabilized materials, the closure is independently tested according to Telcordia GR-771-CORE standards, with some models achieving Internet Protocol (IP) 68 ratings for environmental sealing. The closure operates effectively across temperature ranges from -40°F to +149°F.
Typical models measure 16 inches in length by 10 inches in width by 5.7 inches in height, with splice capacities supporting up to 120 single fusion or 288 mass fusion splices using butt/expressed splice configuration. Cable diameter compatibility ranges from approximately 8 mm to 32 mm depending on the model.
The closure supports Fiber To The Home (FTTH) deployment and back-haul networks through direct buried, manhole, aerial, or pole/wall mount installations. Mounting options include aerial, pole, wall, or below-grade configurations using optional mounting kits. Standard kits include multi-port grommets for cable entry and splice trays for organizing and protecting splices.
Dome Closure Supplier for Superior Strength and Reliability
RaxPower is a leading company in the design, development, manufacture, and marketing of optical connectivity solutions for operators, distributors, and importer installers worldwide. Established in 2003 and based in Hebei Province, China, we have over 21 years of experience in the industry.
Our extensive manufacturing capabilities, including 17,000 square meters of production workshops and advanced processes like hot forging, ensure that the Dome Closure is built for superior strength, accurate sizing, and long-term reliability.
We guarantee:
- Competitive prices
- Fast production times with samples delivered in 1-3 days and general orders in 5-15 days
- Flexible purchasing facilities
- Dedicated support throughout the process
All our products, including the Dome Closure, are manufactured in accordance with international quality norms and hold ISO9001 certification, reinforced by strict quality control measures such as raw material selection, multi-stage testing, and SGS approvals.
Our team of over 170 employees, featuring specialized professionals with extensive telecommunications expertise, works closely with customers to address stock requirements and project-specific needs.
RaxPower is committed to innovation, developing reliable fiber optic products tailored to each application from conception to final production. Contact us today to learn more about how this Dome Closure can meet your specific application needs.
| Parameter | Value |
|---|---|
| Dimensions | 16″ L x 10″ W x 5.7″ H (406 mm x 254 mm x 145 mm) |
| Splice Capacity (Single Fusion) | 120 splices |
| Splice Capacity (Mass Fusion) | 288 splices |
| Configuration | Butt/Expressed Splice |
| Port Quantity | 3 |
| Ground Stud Quantity | 3 |
| Cable Diameter Range | 8 mm to 32 mm (0.315″ to 1.26″) |
| Ambient Temperature Range | -40°F to +149°F (-40°C to +65°C) |
| Mounting Options | Aerial, pole, wall, or below-grade |
| Material | Flame-retardant and UV-stabilized materials |
| IP Rating | IP 68 |
| Standards Compliance | Telcordia GR-771-CORE, RUS listing |
| Sealing Method | Flexible grommet sealing system |
| Key Features | Segmented end plate, Hinged collar system, Integrated air valve |
Frequently Asked Questions (FAQS)
What are the key specifications and features of the Dome Closure?
The RaxPower Dome Closure is constructed from high-quality, UV-resistant materials such as ABS or PC with stainless steel fasteners, offering durability in harsh conditions. It is typically IP68 rated for excellent protection against dust and water ingress, even when submerged. The closure supports up to 120 single fusion splices or 288 mass fusion splices depending on the model and tray configuration, with some variants accommodating higher capacities. Cable ports range from 3 to 9 across different models, designed to support various flat or round cable profiles.
What mounting and installation options are available?
The Dome Closure offers flexible installation across multiple environments, including direct buried, manhole, aerial, or pole/wall mount configurations. The hinged collar system enables quick re-entry without special tools, reducing overall installation and maintenance costs while simplifying upgrades.
What accessories are included with the Dome Closure?
Standard kits often include assorted grommets for cable sealing and may come with splice trays; customized accessory options are available to meet specific project requirements.
